MX-C250 SIMULATION 6 – 80
92 1 - 3 Adjustment value CI signal ON detection time 155ms 0 0 0
165ms 0 0 1
175ms 0 1 0
185ms 0 1 1
195ms 1 0 0
205ms 1 0 1
215ms 1 1 0
225ms 1 1 1
4 Adjustment value Ring ON OFFSET 0 : No 1 : +100ms Two states input
5 Adjustment value Ring OFF OFFSET 0 : No 1 : +100ms Two states input
6 - 8 Not used
93 1 - 8 Adjustment value CI signal Threshold value Not used at this moment Two states input
94-
95
Not used
96 1 Adjustment value Telephone/FAX CNG judgement 0 : Perform CNG judgement 1 : Does not perform CNG
judgement
2 Adjustment value Telephone/FAX CNG 4s observa-
tion
0 : Observe 4s 1 : Does not observe 4s.
3 - 8 Not used
97 1 Adjustment value Telephone/FAX CNG judgement 0 : Perform CNG judgement 1 : Does not perform CNG
judgement
2 - 3 Setting Time out setting when the image
cannot be detected during receiv-
ing the data (V1.7)
30s 0 0
40s 0 1
50s 1 0
60s 1 1
4 - 7 Adjustment value Maximum signal send level Setting range
0(0dBm) - 15 (-15dBm)
Two states input
8 Adjustment value Maximum signal send level adjust-
ment
0 : Not used 1 : 0.5dBm adjustment Two states input
98 1 FAX initial setting ECM byte/frame 0 : 256[byte/frame] 1 : 64[byte/frame]
2 FAX transmission
setting
JBIG encode line template selec-
tion
0 : 3 line template 1 : 2 line template
3 FAX initial setting Apply with the one stripe and one
page length when receiving the
JBIG data.
0 : Applied 1 : Not applied
4 FAX initial setting JBIG encode TP mode 0 : TP mode invalid 1 : TPmode valid
5 FAX initial setting Last stripe 0 : Applied 1 : Not applied
6 - 7 FAX initial setting Timer setting between flag and
address (V.21 to FSK)
6s 0 0
15s 0 1
30s 1 0
120s 1 1
8 Waiting time between flames 0 : 3.4s 1 : 4.4s
99 1 Adjustment value Time up time on v.8 mode 0 : 10s 1 : 15s
2 Adjustment value Timer out between flames 0 : Does not check 1 : Check
3 - 4 Setting Minimum flag numbers between
flames
1-flag 0 0
2-flag 0 1
3-flag 1 0
4-flag 1 1
5 - 6 Setting Time out setting when the image
cannot be detected during receiv-
ing the data
30s 0 0
60s 0 1
90s 1 0
120s 1 1
7 - 8 Setting PPR occurrence number limitation
when the image cannot be
detected during receiving the data
No limitation 0 0
5 times 0 1
10 times 1 0
15 times 1 1
100 1 FAX initial setting Moves to non-V.34 communication 0 : Does not move 1 : Move
2 - 6 Adjustment value Timeout value used by the answer-
ing modem from the beginning of
the +FRH=FSKL command to the
+A8I:0 indicator
Setting range
0 - 26s
Two states input
7 - 8 Setting Threshold of Packet error ratio Not used 0 0
100% 0 1
50% 1 0
33.3% 1 1
SW
No.
Bit
No.
System set-
tings
Item SW selection and function Remarks
