MX-C250 SIMULATION 6 – 6
66 1 Used to display the FAX-related soft SW (2 - 150) on the LCD to allow changing the soft SW while checking
with the LCD.
FAX
2 Used to enter a country code and set the default value for the country code. FAX
4 Used to send the selected signals to the line and the main unit speaker. FAX
7 Used to output all image data saved in the image memory of FAX part. FAX
8 Used to send the selected sound messages to the line and the speaker. FAX
10 Used to clear the FAX image data. FAX
11 Used to send the selected signal at 300bps to the line and the speaker. FAX
13 Used to execute the dial send test. FAX
17 Used to send the DTMF signal to the line and the speaker. FAX
21 Used to print the selected items (FAX setting list, software SW list, protocol monitor). FAX
30 Used to display the TEL/LIU status change, The display is highlighted by status change. FAX
31 Used to set ON/OFF the port for output to TEL/LIU. FAX
32 Used to check the fixed data received from the line and to display the result. FAX
33 Used to execute detection of various signals with the line connected and to display the detection result. When
a signal is detected, the display is highlighted.
FAX
34 Used to execute the send test and display the time for sending (receiving) the image data during sending the
test data on LCD.
FAX
67 25 Printer color balance adjustment (Manual adjustment) Printer
31 Used to clear the calibration value. Printer
33 Used to change the gamma of the printer screen. Printer
34
Used to set the density correction in the printer high density section. (Support for the high density section
tone gap)
Printer
36 Used to adjust the density in the low density section. Printer
52
Used to reset the printer color balance adjustment (adjustment for each dither) to the default value. (The set
values of SIM67-33 are set to the default values.)
