Interval Checklist
500k 1000k 3000k Process Section (Cont’d):
Sim 24-04 Clear MAIN CHARGER K Counter
(only when Main Charge Kit is replaced)
Sim 24-04 Clear MC CLEAN K Counter
(only when Main Charge Kit is replaced)
Sim 24-04 Clear OZONE/EXHAUST FILTER Counter
(only when Ozone Filter Kit is replaced)
Sim 44-03 Dark Potential Adjustment
Sim 44-06 Process Control Execution [Force]
Sim 44-26 Half Tone Process Control [Force]
Sim 46-74 Auto Grey Balance Adjustment
Fuser Section:
Replace Fuser Maintenance Kit: [MX-950KC] :-
• Upper separation pawl x6.
• Lower separation pawl x4.
•
Fuser front Paper guide.
x Replace Heat Roller Kit [MX-950HK]:-
• Upper heat roller unit.
• Lower heat roller unit.
x x Replace Upper Heat Lamp [RLMPU0848FCPZ – MX-M904]
[RLMPU0763FCPZ – MX-M1054/1204]
x x Replace Sub Thermistor [RDTCT0189FCZ2]
x x Replace Fuser Coupling Gear [NGERH1851FCZZ]
Replace Web Cleaning Kit [MX-950WC]
• Web roller.
• Web roller bearing x2
• Web backup roller
• Web backup bearing x2
• Web guide sheet
• Web guide shaft bearing x2
x x Replace Web Motor [RMOTD0953FCPZ]
Sim 24-04 Clear FUSING WEB Counter
(only when Web Cleaning Kit is replaced)
Sim 24-04 Clear SEPARATE PAWL Counter
(only when Fuser Maintenance Kit is replaced)
Sim 24-04 Clear FUSING WEB Counter
(only when Web Cleaning Kit is replaced)
x Sim 24-04 Clear FUSING ROLLER Counter
(only when Heat Roller Kit is replaced)
x Sim 24-04 Clear PRESS ROLLER Counter
(only when Heat Roller Kit is replaced)
