MX-M182 SIMULATIONS 7-39
46 39 FAX IMAGE adjustment
Used to adjust the resolution and the filer in the FAX mode.
48 01 Main/sub scanning magnification ratio adjustment
Used to adjust the magnification ratio in the main scanning (front/rear) direction and the sub scanning
direction.
When this simulation is executed, the selection window of the adjustment items and the current set value
are displayed
The adjustment value is in the range of 1 - 99.
When the adjustment value is increased by 1, the ratio is increased by 0.1%.
Select an adjustment item (mode) with the arrow keys and enter a desired value with numeric keys.
When [OK] key is pressed, the entered value is saved to the EEPROM and the machine shifts to the copy
execution window.
After completion of copying, the machine returns to the adjustment value input window.
When [START] key is pressed instead of [OK] key, the machine shifts to the copy execution window and
performs copying.
Default:
F-R: 50
SCAN: 50
Main
code
Sub
code
Contents Remark
Sim46-39 FAX IMAGE
Sim46-39 FAX IMAGE
1 - 7 input
0 - 2 input
[OK] key
[OK] key
[BACK] key
[BACK] key
[OK] key
Sim46-39 FAX IMAGE
Sim46-39 FAX IMAGE
Sim46-39 FAX IMAGE
1:STD. 1
2:FINE 1
3:S-FINE 1
(1 - 7 ) X
STD. X
(0 - 2 ) Y
STD. Y
EXEC
STD. Y
SCAN EXEC
STD. Y
PRINT EXEC
Sim46-39 FAX IMAGE
4:U-FINE 1
5:FINE/HT 1
6:S-FINE/HT 1
(1 - 7 ) X
Sim46-39 FAX IMAGE
7:U-FINE/HT 1
(1 - 7 ) X
The current set value of each resolution is displayed.
Specify a resolution
to be set.
Specify the kind
of a filter to be set.
Self print operation is executed.
(The specified kind of the filter is used.)
The specified filter is used even
in the normal operation.
Scanning operation
Printing operation
* When "Interrupt" key is pressed on a window other than the operation window, the display shifts to the sub code input window.
Sim48-1 COPY MAG.
1:F-R
2:SCAN
[ 1- 99]
50
50
50
(Adjustment item selection window)
Display text array : Adjustment mode
1: F-R : Main scan direction magnification ratio (OC/SPF/RSPF)
2: SCAN : Sub scan direction magnification ratio (OC)
Ready to copy.
S
100%
8 1/2×11
(Copy start window)
Copies in progress.
S
100%
8 1/2×11
(Copy execution window)
Adjustment
item selection
window
Copy start
window
Copy execution
window
End of copy execution
[BACK] key
[START] key
[START] key
[OK] key
