MX-M182 SIMULATIONS 7-50
61 02 Laser power correction ON/OFF (Invalidity)
Enable/Disable of the LSU laser power correction during the operation is set.
When [START] key is pressed, the entered set value is saved and the machine enters the sub code input
standby mode.
Note: Changing the setting does not affect the operation.
Default:
0
03 HSYNC output check
When this simulation is executed, the polygon motor is rotated for 30sec together with the LEND signal.
"EXEC" (indicating execution) and "HSYNC" (HSYNC sensor detecting status) are displayed.
Every time when the HSYNC signal is detected, "HSYNC" display is highlighted for 100ms.
63 01 Shading check
Used to display the detection level when the lamp of the white plate for shading correction is lighted.
When the simulation code is entered, the initial window is displayed to urge execution. Press [OK] key or
[START] key to start the simulation. The contents of the operations are as follows:
1. The mirror base unit is shifted to the white plate for shading correction.
2. The copy lamp is lighted.
3. "0" is displayed until the copy lamp light quantity is stabilized.
4. When the light quantity is stabilized, the level of 1 pixel on the CCD center which is not corrected is
displayed in hexadecimal.
* The white level is displayed for about 10sec. The data update cycle is about 1sec.
5. After passing 10sec, the machine returns to the sub code input window.
64 01 Self print
Used to perform printing of one page disregarding the optical system status. Also when the print command
is issued from the host, printing is performed.
When this simulation is executed, warm-up is performed and the ready lamp is lighted. (Since, however, the
optical system is invalid, initializing is not performed.)
There are following twenty-one self-printable patterns. Use numeric keys to select a pattern.
The selected pattern is displayed on 7-segment LED.
Main
code
Sub
code
Contents Remark
Code number : Mode
0 : Correction Enable
1 : Correction Disable
Sim61-2 LASER PWR
1:LASER POWER
[ 0 - 1]
1
1
Sim61-3 LSU CHECK
EXEC
[OK] key or [START] key
Sim61-3 LSU CHECK
PRESS OK KEY EXEC
（Initial window）
HSYNC
(Execution window)
Sim63-1 SHADING
061
[OK] key or [START] key
Sim63-1 SHADING
PRESS OK KEY EXEC
Code
number
Print pattern Image output
0 Grid pattern (1) 1/236
1 (*1) (2) 1/128
2 (3) 1/255
3 (4) 2/254
4 Dot print (1) 1/1
5 (2) 2/2
6 (3) 1/255
7 Equal-pitch pattern (1) 1/1
8 M by N (Sub scan) (2) 1/2
9 (3) 2/2
10 Equal-pitch pattern (1) 1/1
11 M by N (Main scan) (2) 1/2
12 (3) 2/2
13 Black background
area (A4/A4R)
(1) 1%
14 (Paper F-R edge) (2) 6%
15 (3) 35%
16 Black background
area (whole surface)
No pattern
17 White background
area (whole surface)
No pattern
18 HT (whole surface) No pattern
19 Black rectangle No pattern
20 Black lead edge No pattern
21 Cross pattern No pattern
Code
number
Print pattern Image output
To Next Page
