60
MANUAL FINISHING
PAPER LOADING ORIENTATION
When using the staple, punch or the paper folding function, the original must be placed as shown below to enable
stapling or punching in the desired position on the paper.
STAPLE
To use the staple function, you need to mount a
finisher (100-sheet stapling) or saddle stitch finisher
(100-sheet stapling).
To use the saddle stitch function, you need to mount a
saddle stitch finisher (100-sheet stapling).
PUNCH
A punch module is required for paper punch.
FOLD
A folding unit is required to be installed in order to use
paper folding functions other than saddle folds.
To use the saddle fold function, you need to mount a
saddle stitch finisher (100-sheet stapling).
Touch panel key Orientation Result
Touch panel key Orientation Result
1 Staple
at Back
A
A
A
A
1 Staple
at Front
A
A
2 Staples
A
A
A
A
Saddle
Stitch
AB
2 Hole
Punch
A
A
A
A
Touch panel key Orientation Result
Saddle
Fold
AB
B
A
Half Fold
AB
A
B
C-Fold
ABC
A
C
Accord-
ion Fold
ABC
A
C
Double
Fold
ABCD
D
A
Z-Fold
ABCD
A
B
D
