Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
108
PG-A10S
PG-A10S-SL
AN-A10T
ERSATZTEILLISTE
AUSTAUSCH VON TEILEN
Ersatzteile, die besondere Sicherheitseigenschften haben, sind in
dieser Anleitung markiert. Elektrische Komponenten mit solchen
Eigenshaften sind in den Ersatzteil durch "å" gekenn-zeichnet.
Der Gebrauch von Ersatzteilen, die nicht deselben Sicherheits-
eigenschaften haben wie die vom Hersteller empfohlenen ud in der
Bedienungsanleitung angegebenen, können zur Ursache von
Blitzeinschlägen, Bränden und anderen Gefahren werden.
WIE MAN ERSATSTEILE BESTELLT
Damit Ihre Bestellung promt und korrekt ausgeführt wird, geben Sie
bitte folgende Informationen.
1. MODELL NR. 2. REF. NR.
3. ERSATZTEIL NR. 4. BESCHREIBUNG
5. KODE 6. QUANTITÄT
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTKB840FE01
MAIN UNIT
DUNTKB840FE01 - Main Unit —
DUNTKB601DE01 - R/C Receiver Unit —
RDENCA029WJZZ - Power Unit —
RDENCA028WJZZ J Ballast Unit BU
(Unit Replacement Item)
INTEGRATED CIRCUITS
IC1101 VHiCXA7000R-1Q J CXA7000R BB
IC1103 VHiNJM2902V-1Y J NJM2902V AD
IC1104 VHiM62392FP-1Y J M62392FP AM
IC1105 VHiNJM2904V-1Y J NJM2904V AF
IC1201 VHiCXA7000R-1Q J CXA7000R BB
IC1301 VHiCXA7000R-1Q J CXA7000R BB
IC1701 VHiPQ05DZ1U-1Y J PQ05DZ1U AG
IC1702 VHiPQ05DZ1U-1Y J PQ05DZ1U AG
IC1703 VHiPQ3DZ13U-1Y J PQ3DZ13U AG
IC1704 VHiSi3025LA-1Y J SI-3025LSA-TL AF
IC1705 VHiPQ05DZ1U-1Y J PQ05DZ1U AG
IC1706 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1707 VHiNJM431M/-1Y J NJM431M AE
IC1708 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1709 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1712 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1713 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1714 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1715 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC1716 VHiPQ3DZ13U-1Y J PQ3DZ13U AG
IC2002 VHiTE7780++-1Q J TE7780 AW
IC2006 VHiSP3220E+-1Y J SP3220ECY/TR AM
IC2007 VHiAHCT08PW-1Y J SN74AHCT08PW AD
IC2601 VHiCXD3526G-1Q J CXD3526GG BE
IC2602 VHi74F86NSR-1Y J SN74F86NSR AD
IC2603 VHiBD4729G+-1Y J BD4729G-TR AD
IC2604 VHiSNAT541P-1Y J SN74AHCT541PWR AF
IC2605 VHiHN24256T-1Y J IC AT
IC2606 VHiSNAT541P-1Y J SN74AHCT541PWR AF
IC2608 VHiSi3025LA-1Y J SI-3025LSA-TL AF
IC3101 VHiSN2G04CT-1Y J SN74AHC2G04HDC AE
IC3102 VHiCXA2101Q-1Q J CXA2101AQ-TL BE
IC3104 VHiFSAV330T-1Y J FSAV330MTCX AN
IC3105 VHiTB1274AF1EQ J TB1274AF AX
IC3301 VHiDA7056AT-1Y J TDA7056AT/N2 AM
IC3506 VHiTC90A69F-1Y J TC90A69F AT
IC4001 VHiBR24C21F-1Y J BR24C21F-E2 AG
IC5001 VHiSN1G00DC-1Y J SN74AHC1G00HDC AB
IC5002 VHiSNT1G08C-1Y J SN74AHCT1G08DC AD
IC5003 VHiLV123AT+-1Y J SN74LV123APWR AF
IC5004 RH-iXA202WJN2Y J PIC12C509A-04 AP
IC5005 VHiNJM2901V-1Y J NJM2901V AE
PARTS LIST
PARTS REPLACEMENT
Parts marked with "å" are important for maintaining the safety of
the set. Be sure to replace these parts with specified ones for main-
taining the safety and performance of the set.
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. CODE 6. QUANTITY
in USA: Contact your nearest SHARP Parts Distributor.
For location of SHARP Parts Distributor,
Please call Toll-Free; 1-800-BE-SHARP
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100.
★ MARKIERUNG : ERSATZTEILE-LIEFERUNG★ MARK: SPARE PARTS-DELIVERY SECTION
