Sharp PN-L803C Service Manual

PN-L803C/80TC3 DISASSEMBLY AND ASSEMBLY 6 - 21
3) Open the 13 clamps (Black) and remove the LCD Module harness, the Power-Main harness and the
Speaker harness from them as shown in the following figure. Then, remove all clamps.
4) Open the two clamps (White) and remove the LCD Module harness from them as shown in the
following figure. Then, remove all clamps.
LCD Module
harness
Powe
r
-Main harness
Speaker harness
Speaker harness
Powe
r
-Main harness
LCD Module
harness
