Sharp PN-L803C - Connector Table

PN-L803C/80TC3 HARDWARE DESCRIPTIONS 8 - 8
4. CONNECTOR TABLE
■Main PWB
CN No. No. Function
Speaker Terminal 1 R+
2 R-
3 L-
4 L+
CN1201
Audio Output
1 Gnd
2 L
3 R
CN700
Display Port Output
1 MainLane0+
2 Gnd
3 MainLane0-
4 MainLane1+
5 Gnd
6 MainLane1-
7 MainLane2+
8 Gnd
9 MainLane2-
10 MainLane3+
11 Gnd
12 MainLane3-
13 Gnd
14 Gnd
15 Aux+
16 Gnd
17 Aux-
18 Hot Plug Detect
19 Gnd
20 3.3V
CN2403
CN2404 for Service
USB-A port
1 VCC
2 D-
3 D+
4 GND
CN2400,CN2401
USB-B port
1 VCC
2 D-
3 D+
4 GND
CN2001
RJ45
1 TD+
2 TD-
3 TCT
4 RD+
5 RD-
6 RCT
7 N.C
8 GND
CN No. No. Function
CN1402
PC CTRL terminal
1 PC ON
2 N.C
3 N.C
4 GND
CN200,CN201
Mini D-sub 15pin
1 Red Video Signal
2 Green Video Signal
3 Blue Video Signal
4 N.C
5 GND
6 GND
7 GND
8 GND
9 +5V
10 GND
11 N.C
12 SDA
13 Hsync Signal
14 Vsync Signal
15 SCL
CN302
Display Port Input
1 MainLane3-
2 Gnd
3 MainLane3+
4 MainLane2-
5 Gnd
6 MainLane2+
7 MainLane1-
8 Gnd
9 MainLane1+
10 MainLane0-
11 Gnd
12 MainLane0+
13 Gnd
14 Gnd
15 Aux+
16 Gnd
17 Aux-
18 Hot Plug Detect
19 Gnd
20 3.3V
