Sharp PN-L803C Service Manual

PN-L803C/80TC3 HARDWARE DESCRIPTIONS 8 - 9
CN No. No. Function
CN300,CN301,CN303
HDMI Input 1,
HDMI Input 2,
HDMI Input 3
1 TMDS Data 2+
2 GND
3 TMDS Data 2-
4 TMDS Data 1+
5 GND
6 TMDS Data 1-
7 TMDS Data 0+
8 GND
9 TMDS Data 0-
10 TMDS Clock+
11 GND
12 TMDS Clock-
13 CEC
14 N.C
15 SCL
16 SDA
17 GND
18 +5V
19 Hot Plug Detect
CN1200,CN1202
Audio Input 1,
Audio Input 2
1 Gnd
2 L
3 R
CN1401 for Service
RS-232C
1 Gnd
2 RXD
3 TXD
CN1300
Internal Speaker Terminal
1 OUT L-
2 OUT L+
3 N.C
4 OUT R-
5 OUT R+
CN No. No. Function
CN1100
LCD Connector
1 ROM_WP
2 N.C
3 PE
4 DET_SYNC
5 Not used(GSP/PWM1)
6 VCOM_WP
7 I2C_READY
8 Not used (L/R_REF)
9 DET_POW
10 TCON_SCL
11 TCON_SDA
12 Not used (OFL)
13 GND
14 Not used (CS_EN)
15 N.C
16 GND
17 N.C
18 N.C
19 N.C
20 N.C
21 N.C
22 N.C
23 GND
24 TXD+
25 TXD-
26 GND
27 GND
28 TXC+
29 TXC-
30 GND
31 GND
32 TXB+
33 TXB-
34 GND
35 GND
36 TXA+
37 TXA-
38 GND
39 LOCKN
40 Not used (HTPDN)
41 GND
