Sharp PN-L803C Service Manual

PN-L803C/80TC3 HARDWARE DESCRIPTIONS 8 - 17
■LED Power Supply PWB
CN No.
No. Function
CN7001 L AC(L)
N AC(N)
CN7002 1 PNL12V
2 PNL12V
3 GND
4 GND
5 UR13.2V
6 UR13.2V
7 UR13.2V
8 UR13.2V
9 GND
10 GND
11 GND
12 GND
13 AC_DET
14 PS_ON
15 BU5V
16 PNL_POW
17 PWM1
18 NC
19 DIMMER
20 20 NC
21 OFL
22 22 ERROR
23 PWM2
24 24 STB
CN7005 1
LED1+ (LED21+/22+)
2
LED1-1 (LED22-)
3
LED1-2 (LED21-)
4
LED1+ (LED11+/12+)
5
LED1-3 (LED12-)
6
LED1-4 (LED11-)
7
LED1+ (LED51+/52+)
8
LED1-5 (LED52-)
9
LED1-6 (LED51-)
10
LED1+ (LED41+/42+)
11
LED1-7 (LED42-)
12
LED1-8 (LED41-)
13
LED1+ (LED31+/32+)
14
LED1-9 (LED32-)
15
LED1-10 (LED31-)
CN7007
1 LED2+ (LED71+/72+)
2 LED2-1 (LED72-)
3 LED2-2 (LED71-)
4 LED2+ (LED61+/62+)
5 LED2-3 (LED62-)
6 LED2-4 (LED61-)
7 LED2+ (LEDA1+/A2+)
8 LED2-5 (LEDA2-)
9 LED2-6 (LEDA1-)
10 LED2+ (LED91+/92+)
11 LED2-7 (LED92-)
12 LED2-8 (LED91-)
13 LED2+ (LED81+/82+)
14 LED2-9 (LED82-)
15 LED2-10 (LED81-)
■
5V Power Supply PWB
CN No.
No. Function
CN100 1 L_IN
2 -
3 N_IN
CN200 1 5V
2 GND
■
AC Relay PWB
CN No.
No. Function
CN1 1 L_IN
2 -
3 N_IN
CN2 1
L_OUT (For 5V PSU)
2
-
3
N_OUT (For 5V PSU)
CN3 (RED) 1
L_OUT (For LED PSU)
2
-
3
N_OUT (For LED PSU)
CN5 1 PS_ON_RELAY1
2 PS_ON_RELAY2
3 GND
