Sharp PN-L803C Service Manual

PN-L803C/80TC3 INSTALLATION, ADJUSTMENT, SETTING, OPERATION 2 - 23
ITEM DETAIL 1 DETAIL 2 ADJUSTMENT
Input terminal
DisplayPort
HDMI1［AV］
HDMI1[PC]
HDMI2［AV］
HDMI2[PC]
HDMI3［AV］
HDMI3[PC]
D-SUB1［RGB］
D-SUB1［VIDEO］
D-SUB1［COMPONENT］
D-SUB2［RGB］
POWER ON DELAY ● ● ● ● ● ● ● ● ● ● ●
POWER ON DELAY ● ● ● ● ● ● ● ● ● ● ●
OFF ● ● ● ● ● ● ● ● ● ● ●
ON ● ● ● ● ● ● ● ● ● ● ●
INTERVAL ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Value 1 - 60 ● ● ● ● ● ● ● ● ● ● ●
SELF ADJUST ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
SELF ADJUST ● ● ● ● ● ● ● ● ● ● ●
OFF ● ● ● ● ● ● ● ● ● ● ●
ON ● ● ● ● ● ● ● ● ● ● ●
START TIMING ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Value 1 - 20 ● ● ● ● ● ● ● ● ● ● ●
TOUCH OUTPUT INVALID DISP. ● ● ● ● ● ● ● ● ● ● ●
TOUCH OUTPUT INVALID ICON ● ● ● ● ● ● ● ● ● ● ●
OFF ● ● ● ● ● ● ● ● ● ● ●
ON ● ● ● ● ● ● ● ● ● ● ●
CHANGE DISPLAY POSITION ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
UPPER LEFT ● ● ● ● ● ● ● ● ● ● ●
LOWER LEFT ● ● ● ● ● ● ● ● ● ● ●
UPPER RIGHT ● ● ● ● ● ● ● ● ● ● ●
LOWER RIGHT ● ● ● ● ● ● ● ● ● ● ●
TOUCH OPERATION MODE ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
AUTO ● ● ● ● ● ● ● ● ● ● ●
MULTI-TOUCH MODE ● ● ● ● ● ● ● ● ● ● ●
MOUSE MODE ● ● ● ● ● ● ● ● ● ● ●
TOUCH PANEL MODE TOUCH PANEL MODE is only valid for PC input. ● △ ● △ ● △ ● ● △ △ ●
OFF ● ● ● ● ● ● ● ● ● ● ●
ON ● ● ● ● ● ● ● ● ● ● ●
PIP/PbyP ● ● ● ● ● ● ● ● ● ● ●
Cannot operate.)
PIP MODES ● ● ● ● ● ● ● ● ● ● ●
OFF ● ● ● ● ● ● ● ● ● ● ●
PIP ● ● ● ● ● ● ● ● ● ● ●
PbyP ● ● ● ● ● ● ● ● ● ● ●
PbyP2 ● ● ● ● ● ● ● ● ● ● ●
PIP SIZE ● ● ● ● ● ● ● ● ● ● ●
Value ● ● ● ● ● ● ● ● ● ● ●
PIP H-POS ● ● ● ● ● ● ● ● ● ● ●
Value ● ● ● ● ● ● ● ● ● ● ●
PIP V-POS ● ● ● ● ● ● ● ● ● ● ●
Value ● ● ● ● ● ● ● ● ● ● ●
PIP BLEND ● ● ● ● ● ● ● ● ● ● ●
Value ● ● ● ● ● ● ● ● ● ● ●
