Sharp PN-L803C Service Manual

PN-L803C/80TC3 INSTALLATION, ADJUSTMENT, SETTING, OPERATION 2 - 25
ITEM DETAIL 1 DETAIL 2 ADJUSTMENT
Input terminal
DisplayPort
HDMI1［AV］
HDMI1[PC]
HDMI2［AV］
HDMI2[PC]
HDMI3［AV］
HDMI3[PC]
D-SUB1［RGB］
D-SUB1［VIDEO］
D-SUB1［COMPONENT］
D-SUB2［RGB］
AUTO INPUT SELECT PRIORITY ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
DisplayPort ● ● ● ● ● ● ● ● ● ● ●
Value "-",1 - 7 ● ● ● ● ● ● ● ● ● ● ●
HDMI1 ● ● ● ● ● ● ● ● ● ● ●
Value "-",1 - 7 ● ● ● ● ● ● ● ● ● ● ●
HDMI2 ● ● ● ● ● ● ● ● ● ● ●
Value "-",1 - 7 ● ● ● ● ● ● ● ● ● ● ●
HDMI3 ● ● ● ● ● ● ● ● ● ● ●
Value "-",1 - 7 ● ● ● ● ● ● ● ● ● ● ●
D-SUB1 ● ● ● ● ● ● ● ● ● ● ●
Value "-",1 - 7 ● ● ● ● ● ● ● ● ● ● ●
D-SUB2 ● ● ● ● ● ● ● ● ● ● ●
Value "-",1 - 7 ● ● ● ● ● ● ● ● ● ● ●
LOGO SCREEN ● ● ● ● ● ● ● ● ● ● ●
OFF ● ● ● ● ● ● ● ● ● ● ●
ON ● ● ● ● ● ● ● ● ● ● ●
INPUT SIGNAL - - - - - - - ○ - - ○
480 LINES - - - - - - - ● - - ●
AUTO - - - - - - - ● - - ●
640x480(640x480) - - - - - - - ● - - ●
848x480(848x480) - - - - - - - ● - - ●
768 LINES - - - - - - - ● - - ●
AUTO - - - - - - - ● - - ●
1024x768(1024x768) - - - - - - - ● - - ●
1280x768(1280x768) - - - - - - - ● - - ●
1360x768(1360x768) - - - - - - - ● - - ●
1366x768(1360x768) - - - - - - - ● - - ●
1050 LINES - - - - - - - ● - - ●
1400x1050(1400x1050) - - - - - - - ● - - ●
1680x1050(1680x1050) - - - - - - - ● - - ●
ZOOM2 SPECIAL SETTING - - - - - - - ● - - ●
OFF - - - - - - - ● - - ●
ON - - - - - - - ● - - ●
SCAN MODE - - - - - - - ○ - - ○
MODE1 - ● - ● - ● - - ● ● -
MODE2 - ● - ● - ● - - ● ● -
MODE3 - ● - ● - ● - - ● ● -
COLOR SYSTEM - - - - - - - - ○ - -
AUTO - - - - - - - - ● - -
PAL - - - - - - - - ● - -
PAL-60 - - - - - - - - ● - -
SECAM - - - - - - - - ● - -
NTSC3.58 - - - - - - - - ● - -
NTSC4.43 - - - - - - - - ● - -
BACKLIGHT OFF ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
OFF ● ● ● ● ● ● ● ● ● ● ●
ON ● ● ● ● ● ● ● ● ● ● ●
