Sharp PN-L803C Service Manual

PN-L803C/80TC3 INSTALLATION, ADJUSTMENT, SETTING, OPERATION 2 - 29
ITEM DETAIL1 DETAIL2 DETAIL3 DEFAULTE VALUE
TOUCH INPUT SELECT
BOTTOM USB BOTTOM INPUT TERM.
SIDE USB SIDE INPUT TERM.
COMMUNICATION SETTING
RS-232C/LAN SELECT
BAUD RATE
LAN SETUP
DHCP CLIENT ON
IP ADDRESS 192. 168. 150. 2
SUBNET MASK 255. 255. 255. 0
DEFAULT GATEWAY 0. 0. 0. 0
MONITOR MONITOR LANDSCAPE
OSD H-POSITION 50
OSD V-POSITION 50
OPERATION MODE MODE 1
STANDBY MODE STANDARD
OFF IF NO OPERATION OFF
POWER ON DELAY
POWER ON DELAY OFF
INTERVAL 1
SELF ADJUST
SELF ADJUST ON
START TIMING 2
TOUCH OUTPUT INVALID DISP.
TOUCH OUTPUT INVALID ICON OFF
CHANGE DISPLAY POSITION LOWER LEFT
TOUCH OPERATION MODE AUTO
TOUCH PANEL MODE ON
PIP/PbyP PIP MODES OFF
PIP SIZE 1
PIP H-POS 99
PIP V-POS 1
PIP BLEND 0
PIP SOURCE
DisplayPort：D-SUB1 [RGB]
HDMI：D-SUB1 [RGB]
D-SUB：DisplayPort
SOUND CHANGE MAIN
MAIN POS POS1
PbyP2 POS POS2
AUTO OFF AUTO
OTHERS SCREEN MOTION
PATTERN OFF
MOTION TIME 1 0
MOTION TIME 2
Pattern 1/2/3/4
-> 10
POWER MANAGEMENT
HDMI1 to 3[PC], DisplayPort, D-SUB1［RGB］,
D-SUB2
-> ON
HDMI1 to 3[AV], D-SUB1［VIDEO］, D-SUB1
［COMPONENT］
-> OFF
