Sharp PN-L803C

PN-L803C/80TC3 SERVICE MENU/VARIOUS SETTING TOOL OPERATING PROCEDURES 4- 14
To use the Service tool, use the RS-232C connection or LAN
connection.
EX) Screen image of the connection setting
1. RS232C
Communication
setting
COM port number and the Baud rate
can be set for connecting the monitor.
2. LAN
Communication
setting
IP address and the TCP port can be set
for connecting the monitor.
3. Display ID When the Display ID is set for
connecting the monitor by the daisy
chain connection, the Display ID can be
set here.
1
3
2
