Binding Cables
The cables connected to the terminals on the rear of the
monitor can be fastened with the cable clamp.
Attach the cable clamp to the back of the monitor, and fasten
the cables.
Setting the USB ash drive cover
1. Insert the USB ash drive into the USB port.
USB port
2. Attach the USB ash drive cover and secure with the
provided screw.
Insert the claw (1) into the monitor, and while pressing in
the direction of (2), insert the claw (3) into the monitor.
(2)
(3)
(3)
(1)
Screw
(black)
USB flash drive cover
Cable clamp
Cable
TIPS
• If the USB ash drive will be attached, use a USB ash drive with dimensions no greater than 3-1/8 inch (80 mm) (L) × 15/16
inch (25 mm) (W) × 7/16 inch (12 mm) (H).
• To remove the USB ash drive cover, reverse the procedure. Using excessive force may break the claws. Exercise caution.
Caution
• Do not touch any screws other than the black screw.
