E-14
Maintenance (continued)
Installing a new cartridge
Caution:
Do not touch the stylus (needle) to avoid damage to
the stylus. It is best to leave the stylus guard on during
installation.
1 Insert the metal sleeves of the red wire and white wire
to the cartridge pins as shown.
Red wire
White wire
2 Insert the lock tip into the groove at the bottom of the
headshell as shown.
3 Push the cartridge up until it locks with the tip of the
headshell.
■ Cleaning the cabinet
Periodically wipe the cabinet with a soft cloth.
Caution:
● Do not use chemicals for cleaning (gasoline, paint
thinner, etc.). It may damage the cabinet.
● Do not apply oil to the inside of the unit. It may cause
malfunctions.
