E-8
Listening to a vinyl record
1 Press the POWER button to turn on the unit.
-Turn on the external unit (home entertainment receiv-
er or other music system) which is connected to this
turntable via Audio cable.
2 Press the FUNCTION button to select PHONO mode.
3 Lift up the dust cover.
4 Put a vinyl record onto the platter. When playing the
45 rpm vinyl record, remember to use the 45 rpm
adaptor.
USB
5 Select the speed according to the vinyl record you are
playing.
33
45
78
6 Remove the stylus guard and place it to a safe place.
When the phonograph is not in use, put the stylus
guard back on to protect the stylus.
White plastic
stylus guard
7 Release the security hook. Lift the cue lever and move
the tonearm gently to the desired position over the vi-
nyl record. The vinyl record will start spinning. Then,
lower the cue lever slowly.
Reset
Indicator
Security
hook
Cue
lever
