USING
EXTERNAL
UNITS
AUX-1
AUX-2
STEREO
@
AUX-1,AUX-2
input
To
listen
to
or
record
audio
signals
from
external
units
such
as
DAT
or
TV.
1
Use
RCA
cables
to
connect
the
desired
external
unit
to
the
AUX-1
or
AUX-2
sockets.
(red
==>
right
channel,
white
==>
left
channel)
@
To
use
an
external
monaural
equipment,
connect
it
to
either
the
LEFT
or
RIGHT
AUX-2
socket.
Then
set
the
STEREO/
MONO
switch
to
MONO.
2
When
using
the
external
unit
connected
to
the
AUX-2
sockets,
set
the
STEREO/MONO
switch
to
the
proper
position.
When
==s=5
using
stereo
equipment,
set
the
STEREO/MONO
switch
to
STEREO.
When
using
monaural
equipment,
set
the
STEREO/
MONO
switch
to
MONO.
3
Set
the
POWER
switch
on
this
unit
and
the
external
unit
to
ON.
4
Press
the
AUX-1
or
AUX-2
button.
5
Activate
the
external
unit.
6
Start
recording
with
this
unit
if
so
desired.
(See
page
18.)
(PPEFrm
oer
]
Note:
To
prevent
hum
interference,
do
not
bring
this
unit
near
televi-
sions.
m@
Headphones
@
Be
sure
that
your
headphones
have
a
6.3
mm
(1/4)
diameter
plug
and
8
to
25
ohms
impedance.
