3–21
DGB
Type Desk-top
Copy system Dry, electrostatic transfer
Originals Sheets, bound documents
Original size Max. B4
Copy size Max. B4, min. A6
(Feed copy paper lengthwise only.)
Image void: Max. 4 mm (leading and trailing edges)
Max. 3 mm (other edges)
Copy speed*
1
14 copies/min.
Continuous copying Max. 99 copies; subtractive counter
First-copy time*
2
5.9 sec. normal copy mode
Warm up time Approx. 30 sec.
Copy ratio SF-2314: Fixed: 100%
SF-2414 and SF-2514: Variable between 64% to 129% in
1% increments (total 66 steps);
preset at 64%, 70%, 81%, 100%, 115%, 122%, 129%
Exposure system Moving optical source, slit exposure (stationary platen) with
automatic exposure.
SPF: Moving original (SF-2514).
Copy paper feed One paper tray with automatic feed (250 sheets), one manual bypass
Fusing system Heat rollers
Development system Magnetic brush development
Light source Halogen lamp
Power supply Local voltage ±10% (For this copier’s power supply requirements,
see the name plate located on the back of the unit.)
Power consumption Max. 1.4 kW
Overall dimensions 761 (W) x 480 (D) mm
Weight SF-2314 and SF-2414: 24 kg approx.
SF-2514: 28 kg approx.
Copier dimensions SF-2314 and SF-2414: 500 (W) x 481 (D) x 298 (H) mm
SF-2514: 545 (W) x 481 (D) x 370 (H) mm
Operating conditions Temperature: 15°C to 30°C
Humidity: 20% to 85%
Optional equipment Paper feed unit (SF-CM14)
Multi bypass feeder (SF-MF14)
Paper tray (SF-UB14)
*1 The values for copy speed are rounded to the nearest whole number.
*2 First-copy time may differ depending on operating conditions, such as power-supply voltage and room
temperature.
Design and specifications are subject to change for improvement without notice.
PRODUCT SPECIFICATIONS
