Appendix
-77
STANDBY button
UNDO button
H&V LENS SHIFT
button
Power cord
1 Press STANDBY on the projector
or on the remote control to put the
projector into standby mode.
• Disconnect the power cord and unplug the
power cord from the AC socket after the
cooling fan stops.
2 Remove the lens cover.
• Press the lens cover removal button (1).
Slide the lens cover forward (2).
3 Turn the lens in the direction of the
arrow while pressing the lens re-
moval lever to pull the lens out.
Do not attempt to exchange the lens when the
projector is installed hanging from the ceiling.
Injury may occur if the lens cover and lens fall.
Before exchanging the lens, reset lens shift to the
center position. (The lens shift is located at the
center in the factory preset.)
When resetting the lens shift to the center position,
press H&V LENS SHIFT and then press UNDO.
• The lens shift reset screen will be displayed.
Select “Yes” to reset.
Attaching the Optional Lens
Removal lever
To Next Page
