Sharp XL-30H Service Manual

XL-30H/30W
– 8 –
Placing the system
20 cm (8")
10 cm (4")
10 cm (4")
10 cm (4")
3
1
Check the supplied accessories
Remote control × 1
AC power lead (For U.K.)
× 1
FM/AM loop aerial ×1
2 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar)
3
Replace the battery cover.
2
Putting batteries into the remote control
1
Remove the battery cover.
2
Insert the batteries.
AC power lead (For Europe)
× 1
FM aerial × 1
(For-XL30W)
Remote control × 1
AC power lead × 1
AM loop aerial ×1
(For-XL30H)
4
Connections
1 Connect the AM and FM aerials.
2 Connect the speaker system.
3 Connect the AC power lead.
2
1
3
1
2
FM aerial
AM loop aerial
White line
Right speaker
Left speaker
1
2
RATED
LINE VOLTAGE
220V
ı
240V
AC 230 V, 50 Hz
(XL-30H for Europe)
AC 110V - 127V or 220V - 240V, 50/60 Hz
ANTENNA
LOOP
FM
75
OHMS
1
2
3
AM loop aerial
FM aerial
(For XL-30W)
AC 230 V, 50 Hz
(XL-30H for U.K.)
(For XL-30H)
To an AC socket
(For XL-30W)
(For XL-30H/ XL-30W)
