XL-DH20NH
– 1
PRECAUTIONS FOR USING LEAD-FREE SOLDER
1. Employing lead-free solder
Lead-free wire solder for servicing
Ref No.
Description
Parts No.
"MAIN, POWER, DISPLAY, HEADPHONE, USB, iPod, REFRESH PWB" of this model employs lead-free solder.
The LF symbol indicates lead-free solder, and is attached on the PWB and service manuals. The alphabetic
character following LF shows the type of lead-free solder.
2. Using lead-free wire solder
When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with convention
lead wire solder may cause damage or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 C, we recommen
you to use a dedicated soldering bit, if you are not familiar with how to obtain lead-free wire solder or solderin
bit, contact our service station or service branch in your area.
3.
Soldering
As the melting point of lead-free solder (Sn-Ag-Cu) is about 220°C which is higher than the conventional lead
solder by 40°C,and as it has poor solder wettability, you may be apt to keep the soldering bit in contact with the
PWB for extended period of time. However, since the land may be peeled of for the maximum heat-resistance
temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the steady
soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corrected. Make sure to turn
on and off the power of the bit as required. If a different type of solder stays on the tip of the soldering bit, it is
alloyed with lead-free solder. Clean the bit after every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sand paper.
Be careful when replacing parts with polarity indication on the PWB silk.
Examples:
Indicates lead-free solder of tin, silver and copper.
PWB-A 92L701M5673006 MAIN
PWB-B 92L701CM904001 POWER
PWB-C 92L701CM903002 DISPLAY
PWB-D 92L701CM903005 HEADPHONE
PWB-E 92L701CM90300E USB
PWB-F 92L701CM90300W iPod
PWB-G 92L701CM90300Z REFRESH
