XL-DH20NH
5 – 32
Figure 5-28: WIRING SIDE OF DISPLAY PWB (BOTTOM VIEW) (1/2)
WIRE 1
U1
PT6311
DISPLAY PWB-C
A
B
C
D
E
F
G
H
1
23456
Lead-free solder indication
Lead-free solder is used in the DISPLAY PWB.
Refer to "Precautions for handling lead-free solder" for instructions
and precautions.
