System connections
Supplied FM aerial:
Connect the FM aerial wire to the FM ANTENNA 75 OHMS socket
and position the FM aerial wire in the direction where the strongest
signal can be received.
Note:
Placing the aerial on the unit or near the AC power lead may cause
noise pickup. Place the aerial away from the unit for better reception.
Use an external FM aerial if you require better reception.
Consult your dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM
aerial wire.
Make sure to unplug the AC power lead before making any connections.
P B
P R
Wall socket
(AC 220 - 240 V ~ 50/60 Hz)
Left speaker
FM aerial
75 ohms
coaxial cable
External FM aerial
Right speaker
Red Black
(supplied)
To video
input socket
(not supplied)
To HDMI
input socket
To component
video input
sockets
To S-video input socket
To SCART
input socket
To coaxial digital audio input socket
To audio output sockets
(commercially
available)
(commercially
available)
To audio input
socket
(commercially
available)
(not supplied)
(not supplied)
(commercially
available)
 Aerial connection  External FM aerial
