General Information
Controls and indicators (continued)
(XL-MP444H)
! Rear panel
Reference page
1. AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3. Subwoofer Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4. FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5. AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6. Video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
! Front speaker
1. Tweeter
2.Woofer
3. Bass Reflex Duct
4. Speaker Wire
! Subwoofer
1.Sub Duct Pipe
2.Subwoofer
3. Speaker Wire
3
2
1
1
5
4
6
7
2
3
3
4
2
1
Front speaker grilles are removable:
Make sure nothing comes into contact with the
speaker diaphragm when you remove the
speaker grilles.
