Red
Black
Left speaker
Right speaker
FM aerial
Wall socket
(AC 220 - 240 V ~ 50/60 Hz)
Make sure to unplug the AC power cord before making any connections.
Please ensure that the equipment is positioned in a
well ventilated area and ensure that there is at least
10 cm (4”) of free space along the sides, top and back
of the equipment.
Use the unit on a rm, level surface free from
vibration.
Place the speakers at least 30 cm (12”) away from
any CRT TV to avoid colour variations across the TV
screen. If the variations persist, move the speakers
further away from the TV. LCD TV is not prone to such
variation.
Keep the unit away from direct sunlight, strong magnetic
elds, excessive dust, humidity and electronic/electrical
equipment (home computers, facsimiles, etc.) which
generate electrical noise.
Do not place anything on top of the unit.
Do not expose the unit to moisture, to temperatures
higher than 60°C (140°F) or to extremely low
temperatures.
If your system does not work properly, disconnect the
AC power lead from the wall socket. Plug the AC power
lead back in, and then turn on your system.
In case of an electrical storm, unplug the unit for
safety.
Hold the AC power plug by the head when removing it
from the wall socket, as pulling the lead can damage
internal wires.
●
●
●
●
●
●
●
●
●
Speaker connection■
System connections
Connect the black wire to the
minus (–) terminal, and the red
wire to the plus (+) terminal.
Use speakers with an impedance
of 4 ohms or more, as lower
impedance speakers can
damage the unit.
Do not make a mistake when connecting the right and
left speakers. The right speaker is the one on the right
side when you face the unit.
Do not let the bare speaker wires touch each
other.
Do not allow any objects to fall into or to be placed in
the bass reex ducts.
Do not stand or sit on the speakers. You may be
injured.
●
●
●
●
●
●
Precautions■
10 cm (4”)(4”) 10 cm (4”)(4”)
10 cm (4”)(4”)
10 cm (4”)(4”)
Incorrect
The AC power plug is used as a disconnect device and
shall always remain readily operable.
Do not remove the outer cover, as this may result
in electric shock. Refer internal service to your
local SHARP service facility.
The ventilation should not be impeded by covering the
ventilation openings with items, such as newspapers,
tablecloths, curtains, etc.
No naked ame sources, such as lighted candles,
should be placed on the apparatus.
Attention should be drawn to the environmental
aspects of battery disposal.
This unit should only be used within the range of 5°C
- 35°C (41°F - 95°F).
The apparatus is designed for use in moderate
climates.
●
●
●
●
●
●
●
The spec label (*)
The spec label
illustration may be
different from the
actual label used.
(*) Label is located at
the bottom of the
unit.
