56
Removing and Installing the
Lamp Unit
• Be sure to remove the lamp unit using the
handle. Be sure not to touch the glass surface
of the lamp unit or the inside of the projector.
• To avoid injury to yourself and damage to the
lamp, be sure to carefully follow the steps
below.
• Do not loosen other screws except for the
lamp unit cover and lamp unit.
Press SON/STANDBY on the pro-
jector or AON/STANDBY on the
remote control to put the projector
into standby mode.
• Wait until the cooling fan stops.
Warning!
• Do not remove the lamp unit from the
projector right after use. The lamp and
parts around the lamp will be very hot
and may cause burns or injury.
Disconnect the power cord.
• Unplug the power cord from the AC
socket.
• Leave the lamp until it has fully cooled
down (about 1 hour).
Remove the lamp unit cover.
• Turn the projector over. Loosen the user
service screw (1) that secures the lamp
unit cover. Remove the lamp unit cover
(2).
Lamp unit
AN-XR1LP
Info
Optional
accessory
AC socket
User service screw
(for lamp unit cover)
1
2
3
Regarding the Lamp (Continued)
ON/STANDBY button
To Next Page
