3.0 Machine Description/Switch Locations
Switches and Sensors
Module
#1
Module
#2
Name
Description
Plug
#
D3
D6
D21+D24
D7
D23+SW2
D22+SW1
D5
D8
D9+D22
D7
D23
ENC Encoder
GHS Gripper Home Sensor
PCPS Platform Card Present
COST Card Out Transmitter Sensor
COSR Card Out Receiver
CIST Card In Transmitter
CISR Card In Receiving
DHS Door Home Sensor
FCPS Feeder Card Present Sensor
GCPS Gripper Card Present Sensor
CDS Card Drop Sensor
PHS Platform Home Sensor
ALS Red Button Switch
SS Green Button Switch
1
3
4
5
6
7
8
9
10
12
13
26
27
28
Motors
Name Description
Module
#1
Module
#2
Plug
#
POM Pick Off Motor
SUM Speed Up Motor
GM Gripper Motor
PM Platform Motor
M2
M1
M1
M2
19
20
23
24
