6.0 Service Menu
Service Menu
To enter the Service Mode, turn the power switch on while pressing the GREEN
button down until the message panel displays:
Press the GREEN button to step through each Service Menu item.
Software Version
This message will indicate the current version of installed software.
Cleaning Mode
Pressing the RED button in Cleaning Mode activates the pick-off and speed-up
motors at a low speed with increased torque to allow for hand cleaning of the
rollers. Pressing the RED button will cycle from FWD to STOP to REV to STOP.
Press the GREEN button to advance to the next menu item.
Sensors
This mode identifies the on/off state of the switch and sensor inputs.
Service Menu
Deck Mate 1.11
Position Sensor/Switch Normal State I/O Module 1 I/O Module 2
1 CIS 0 D9+D22
2 COS 0 D8
3 FCPS 0 D7
4
PCPS
0
D5
5 PHS 1 D7
6 GHS 1 D3
7 GCPS 0 D21+D24
8 DHS 1 D6
9 CDS 0 D23
Sensors:
000 011 010
Cleaning Mode
