6.0 Service Menu
Download to PC
This menu item allows retrieval of machine history, if the operator is equipped
with the proper cable, adapter, PC and software, by connecting to the COM port
of the PC.
Platform Position Test
Press the RED button to move the platform to two different locations from the
zero (0) home position, typically 1043 and 1343. Monitor the encoder readout
to verify proper operation.
Gripper Position Test
Press the RED button repeatedly to test the grippers’ in and out movement.
Speed Up Motor Test
Press the RED button to control the speed-up motor: Forward – Stop – Reverse.
Pick-Off Motor Test
Press the RED button to control the pick-off motor: Forward – Stop – Reverse.
To exit the Service menu, turn off the power to the shuffler.
Gripper In/Out
Speed Up:
FWD – STOP - REV
Pick Off:
FWD - STOP - REV
Download To PC
Platform Up/Middle/Dn
Encoder = 0
To Next Page
