9.0 Troubleshooting
Green or Red switch will not
work.
Switch is faulty. Replace switch
Faulty I/O board. Swap and/or replace the I/O
board.
VFD message panel is blank. Faulty VFD message panel Replace the VFD.
Faulty I/O board. Replace the I/O board.
Red light and “Close Door”
message at power up.
Faulty Door Home Sensor
(DHS).
Replace Sensor
“Remove Cards” message at
power up.
Faulty Platform Card Present
Sensor (PCPS).
Replace sensor.
Broken #4 PCPS harness. Replace harness.
Poker version door will not
open.
Single Deck or Double Deck
game is selected.
Select “Poker” as game in
Setup Menu.
“Jam. Open Door Manually.
Remove Feeder Cards”
message.
Faulty Feeder Card Present
Sensor (FCPS) sensor.
Replace sensor.
Broken FCPS harness Replace harness.
