70
8. Brake rod
➀ Remove the sprit pin and flat head pin, and
disconnect the brake rods at the brake lever.
9. Lift arm
➀ Remove the bolt and pin, and disconnect the lift
arm and hydraulic lift cylinder.
➁ Remove the lift arm assembly as a set.
10. 4 WD control shift link
➀ Remove the sprit pin, and disconnect the 4WD
control shift link at the bottom.
11. Universal joint assembly
➀ Remove the bolt and disconnect the joint by slide
the input shaft to rearward.
410V
411V
412V
413V
