10
2. Installation
2.3 Installation
Start at step 3 when installing a UPY Series balance. Prepare a plus (+) screw driver for a UPX Series
balance.
1 Place the balance main body upside down. (UPX
only)
!
Caution
Do not operate step 2 with the balance placed
on its side. Place the balance on a smooth
surface.
2 Referring to the explanation label on the bottom
of the balance, turn the two transportation
screws counterclockwise until they tighten
again. (UPY only)
!
Caution
When moving the balance again, turn the two
transportation screws clockwise until they
tighten. (UPX only)
3 Slowly and carefully turn the main body back
over (right side up).
Transportation screws
(only for UPX Series)
Explanation label
(only for UPX Series)
Below-weigh
hook cap
To Next Page
