1.1 Components
a. Large pan model
UP0000x
3
Pan
Supports the object to
be weighed
Large pan windbreak
Even light breezes can have an effect on
measurements, so the windbreak protects
against wind.
The windbreak is not included with models
with a minimum display of 0.1 g.
Labe
l
Sh
ows model name. "Max"
an
d "d" are indications
re
quired by legal metrology,
w
hich do not restrict the
we
ighing range in general
us
e.
Main body
Display panel
Shows weighed result, information
on programming function, indicates
current setting, working function,
necessary operation, and error message
Operatio
n keys
Used
to tare, execute calibration
an
d functions, program functions,
inpu
t numerical values
Level screws
Adjust to level the balance
b. Small pan model (minimum display 0.001g, windbreak standard)
Windbreak set
Even light breezes can have an effect on
measurements, so the windbreak pr
otects against
wind.
Pan
Supports the object to be weighed
Label
Shows model name.
"Max" and "d" ar
e
indications r
equired by
legal metr
ology, which do
not r
estrict the weighing
range in general use.
Main body
Display panel
Shows weighed result, information
on programming function, indicates
current setting, working function,
necessary operation, and err
or message
Operation keys
Used to tar
e, execute calibration
and functions, pr
ogram functions,
input numerical values
Level screws
Adjust to level the balance
UP0000x
3
UP0000x
3
1. Name and Function of Components
