12
Battery level indicator
The battery level is shown as an icon.
Display Battery level
100 - 81%
80 - 61%
60 - 41%
40 - 21%
20 - 1% (red)*
0%
*
The battery level indicator will flash when the battery level is low.
• The cycle computer uses zero to indicate a battery level where assistance cannot be performed. With the SHIMANO STEPS system, the light
can still be lit up for a while when assist stops due to a low battery. Therefore, the above-mentioned battery level may differ from that
which can be checked on the battery.
Turning the light ON/OFF
If a light is connected to the drive unit, this product can be used to operate the light. Refer to "Turning the light ON/OFF
[Light]".
• The light power is linked with the main power. The light cannot be turned ON when the main power is OFF.
