Shini SIC-W User Manual

10(45)
Table 1-2: Specifications List (2)
Model SIC-20W SIC-25W SIC-30W SIC-40W SIC-45W SIC-50W
H(mm) 1450 1450 1450 1760 1760 1760
H1(mm) 765 765 765 910 1078 170
H2(mm) 200 200 200 140 140 120
H3(mm) 190 190 200 190 190 190
W(mm) 1055 1055 1055 1100 1100 1100
W1(mm) 300 300 300 370 459 180
W2(mm) 295 295 215 229 202 325
W3(mm) 205 205 205 230 162 505
D(mm) 2235 2235 2235 2870 2870 3285
P1 cooling water inlet
(inch)
21/2 21/221/2 21/2 21/2 21/2 21/2
P2 cooling water
outlet (inch)
21/2 21/221/2 21/2 21/2 21/2 21/2
P3 freezing water inlet
(inch)
2 2 21/2 21/2 21/2 21/2
P4 freezing water
outlet (inch)
2 2 21/2 21/2 21/2 21/2
P5 water tank outlet
(inch)
11/2 11/2 11/2 1 1 1
P6 water tank
overflow port (inch)
11/2 11/2 11/2 1 1 1
Weight(kg) 750 760 800 1200 145 1750
