1.3.1 Specification List
Table 1-3：Specification List (1)
Model
Item/
Parameters
SIC-3W SIC-5W SIC-8W SIC-10W SIC-12.5W
SIC-15W
Refrigerant
Capacity
1)
kW 8.25 13.8 21.8 29.1 33 43
Kcal/hr 7,095 11,868 18,748 25,026 28,380 36,980
Compressor
Power
(50Hz/60Hz)
kW 2.04 3.32 4.91 6.46 7.33 9.5
HP 3 5 8 10 12.5 15
Refrigerant
Weight (kg) 1.5 2.5 3.8 5 7 8.5
Control Mode Thermostatic expansion valve
Type R22
Evaporator Type Tube-in-shell style
Condenser
Type Tube-in-shell style
In/out water pipe(inch)
1 1
1
/
2
2 2
1
/
2
Cooling water flow
(L/min)
56 65 90 100 130 160
Water Tank Capacity (L) 50 90 105
Pump
2)
(50Hz)
Power (kW) 0.75/0.75/1.1 1.1 1.1/1.5/2.2
Pump Flow (L/min) 50/83/67 80/100/89 130/150/133
Working Pressure
(kgf/cm
2
)
2.0/2.6/3.8 2.0/2.6/3.5 2.0/3/4.2
Total Power (kW)
3)
2.79 4.07 6.01 7.56 8.43 10.6
Pipe
Coupling
(inch)
Chilled Water Outlet 1 1
1
/
2
2
Chilled Water Inlet 1 1
1
/
2
2
Water Tank Outlet 1/2
Water Tank Overflow
Port
1/2
Protective
Devices
Compressor Overload relay
pump Overload relay
Chilled Water Circuit
High and low pressure switch/anti-freeze switch
Water Circuit Flow switch (optional) / water tank level sensor (optional) / bypass valve
Power(VAC)
4
）
3Φ, 400VAC, 50HZ
Measures Exchange 1kW=860 kcal/hr 1RT=3,024kcal/hr 10,000Btu/hr=2,520kcal/hr
We reserve the right to change
specifications without prior noice.
Note:
1) Refrigeration capacity is measured based on the flow 0.172 m3 / (h.k W) and the outlet temperature (7℃)
of chilled water under the environment temperature of 35℃.
2) Low pressure pump is for domestic and Southeast Asia export, customers can change for medium
pressure pumps (use P for short; e.g.: SIC-5A-P) or high pressure pumps (use HP for short; e.g.:
SIC-5A-HP), specific parameters in turn as shown above.
3) Pump power is included in total power.
4) Special orders of machine voltage can be acceptable according to customers’ requests.
