Shini STM-PW Series User Manual

22(65)
2.2.4 Parts List (STM-1220-PW)
Table 2-2：Parts List (STM-1220-PW)
No. Name Part No. No. Name Part No.
1
Control box
-
26 Inner hexagon screw M10×25
YW61102500000
2 Door plate - 27 Flange gasket -
3
Door plate aluminum
handle 6609
YW20660900100 28 Lentil-headed screw M5×10 YW62051000100
4
Base plate of control
box
- 29 Line clamp fixing plate -
5
Thick head screw
M6×20
YW63062000000 30 Big hinge CL219-1 YW06219100000
6 Caster 2" YW03000200000 31 Thick head screw M4×6 YW63040600000
7
HAN YOUNG controller
MT100-01
YE81100010000 32 Inner hexagon screw M8×20 YW61082000200
8 Pressure gauge 0-15kg YW85015000000 33 Spring gasket 8mm YW65008000100
9 Pressure gauge pipe - 34 EGO assembly BH90115000050
10
Teflon pipe with
connector 3/8"×50cm
YW59385000000 35 Thick head screw M3×6 YW63030600000
11 Cover plate - 36 Return pipe parts -
12 Low pressure pipe - 37 Filling water pipe -
13 Heating tank parts - 38 High pressure pipe -
14 Cooling water inlet pipe - 39
Low pressure on-off controller
0-0.8MPa
YE90000800000
15
Water drainage
connector parts
- 40 Hot water by-pass pipe -
16
Filling pipe connector
parts
- 41 Cooling water by-pass pipe -
17
Copper core
M13×1/2PT
BH12131200010 42 Water drainage pipe -
18
Y type filtering water
valve 1/2"
YW57010200000 43 Side plate -
19
Lentil-headed screw
M6×10
YW62061000000 44 Spring gasket 10 YW65010000000
20
Flat gasket
8×22×1.5mm
YW66082200000 45 Inner hexagon screw M10×30 YW61103000100
21 Spring gasket 6 YW65006000100 46 Flat gasket 10.5×20×2mm YW66102000100
22 Flat gasket 6×18×1.0 YW66061800000 47 Butterfly screw M8×15 YW69081500000
23 Hexagon screw M6×25 YW60062500000 48 Spring gasket 8×16×1.5mm YW66081600000
24 Screw M6 YW64080600000 49 Rear plate of control box -
25
Pump MP-100
BM20123400000
* means possible broken parts. ** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
