33(65)
2.3.9 Electrical Components List (STM-PW) (230V)
Table 2-5：Electrical Components List (STM-607-PW) (230V)
NO. Symbol Name Specification Part NO.
1 Q1 Main switch 25A YE10125250000
2 Q2 Circuit breakers* 25A YE40602500000
3 - Excitation break away - YE40023560000
4 K1 Contactors* 220V 50/60Hz YE00601521000
5 K2 Contactors* 220V 50/60Hz YE00602522000
6 K3 Timer 220V 50/60Hz YE86300600000
7 F1 Overload relays* 2.8~4A YE01160280000
8 F11 Fuse box* 32A 2P YE41032200000
9 - Fuse** 2A YE46002000100
10 S1 Thermocouple - -
11 S2 S3 Thermocouple - -
12 S4 Overheat protector* - -
13
S5 S7 Pressure switch 0~8bar YE90000800000
14
S6 Float switch - YE59100000000
15 PC1 A
Circuit board* 100~240VAC 50/60Hz YE81100010000
16
Y1 Y2
Solenoid valve 230VAC 50/60Hz -
17 X1 Terminal board - YE61250040000
18 - Terminal board - YE61253500000
19 - Terminal board - YE61040000000
20 - Terminal board - YE61043500000
21 M1 Motor 230V 50Hz 0.5kW -
22 EH1 Heater** 230V 50Hz 6kW -
23 FM Fan* 230V 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
