Table 2-6：Electrical Components List (STM-1220-PW) (230V)
NO. Symbol Name Specification Part NO.
1 Q1 Main switch 63A YE10636300000
2 Q2 Circuit breakers* 63A YE40606000000
3 - Excitation break away - YE40023560000
4 K1 Contactors* 220V 50/60Hz YE00601621000
5 K2 Contactors* 220V 50/60Hz YE00503500000
6 K3 Timer 220V 50/60Hz YE86300600000
7 F1 Overload relays* 7~10A YE01167100000
8 F11 Fuse box* 32A 2P YE41032200000
9 - Fuse** 2A YE46002000100
10 S1 Thermocouple - -
11 S2 S3 Thermocouple - -
12 S4 Overheat protector* - -
13
S5 S7 Pressure switch 0~8bar YE90000800000
14
S6 Float switch - YE59100000000
15
PC1 A
Circuit board* 100~240VAC 50/60Hz YE81100010000
16
Y1 Y2
Solenoid valve 230VAC 50/60Hz -
17 X1 Terminal board - YE61250040000
18 - Terminal board - YE61253500000
19 - Terminal board - YE61060000000
20 - Terminal board - YE61063500000
21 M1 Motor 230V 50Hz 1.5kW -
22 EH1 Heater** 230V 50Hz 12kW -
23 FM Fan* 230V 50/60Hz -
* means possible broken parts. ** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
