27(65)
2.3.4 Electrical Components List (STM-PW) (400V)
Table 2-3：Electrical Components List (STM-607-PW) (400V)
NO. Symbol Name Specification Part NO.
1 Q1 Main switch 16A YE10021160000
2 Q2 Circuit breakers* 16A YE40601500000
3 - Excitation break away - YE40023560000
4 K1 Contactors* 220V 50/60Hz YE00601521000
5 K2 Contactors* 220V 50/60Hz YE00601800000
6 K3 Timer 220V 50/60Hz YE86300600000
7 F1 Overload relays* 1.8~2.5A YE01160180000
8 F11 Fuse box* 32A 2P YE41032200000
9 - Fuse** 2A YE46002000100
10 F12 Fuse** 2A YE41001000000
11 T Transformer IN=400V OUT=230V 500mA YE70402300800
12 S1 Thermocouple - -
13 S2 S3 Thermocouple - -
14 S4 Overheat protector* - -
15
S5 S7 Pressure switch 0~8bar YE90000800000
16
S6 Float switch - YE59100000000
17 PC1 A
Circuit board* 100~240VAC 50/60Hz YE81100010000
18
Y1 Y2
Solenoid valve 230VAC 50/60Hz -
19 X1 Terminal board - YE61250040000
20 - Terminal board - YE61253500000
21 M1 Motor 400V 50Hz 0.5kW -
22 EH Heater** 400V 50Hz 6kW -
23 FM Fan* 230V 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
