Measurement
Click to enter the measurement interface and the menu is displayed. Click it again to
exit.
Select a feature surface in the plane drop down menu, and select an axis in the
corresponding constraint drop-down menu of the plane. The arrow on the plane corner
indicates the positive direction of the plane, and the selected axis direction will be
consistent with the plane direction.
Select a feature line in the drop-down menu of the line, and select an axis in the drop-
down menu of the line. The arrow of the line indicates the positive direction of the line,
and the direction of the selected axis will be consistent with the direction of the
projection of the line on the selected plane.
Click the drop-down menu to select a point, the position of this point is the origin of the
coordinates (0, 0, 0).
Click Movement to start the coordinates transformation. When the lines are perpendicular
to the plane, the transformation fails, so the movement fails.
Click Reset to cancel all the transformation in the 3-2-1 system movement interface.
Click Close to save the results and exit.
