5. DESCRIPTION OF PARTS VM-5G
-9-
5-2 DESCRIPTION OF PARTS
1 Terminal block
For connection of the input transducers.
Provides analog signals for recorder output.
Provides monitor output through a buffer output terminal.
Provides alarm contact output (DAN.1, DAN.2, ALE.1, ALE2)
(Speed relay output SR1, SR2, SR3, SR4 for the VM-5S Dual Tachometer and VM-5R
Tachometer.)
Provides OK alarm contact output.
• Power supply input
For external contact input (Sequence function, Reset function, Power sequence function)
2 Terminal cover
3 Mounting bracket
For fixing the instrument rack on the instrument panel.
4 Panel set screw
For fixing the monitor unit in the instrument rack.
5 Signal assignment table
Lists the signals assigned to the input / output terminals.
6 Bezel
