2. SPECIFICATIONS VM-5G
-2-
Power supply voltage Input
Tropical
spec.
CE marking *3
0 85 to 264VAC 1 CA Series,CV-86 *1
1 24VDC
2 110VDC
2 CV-85,CV-87 *2
VK,RD,FK,MS
VC,VM-11P,VM-21P
3 Input for VM-51
1CH:VK,FK
2CH:VK,FK
φ I:VK,RD,FK
4 Input for VM-55
1CH:VK-202A,FK-202F
2CH:CV-86,CV-88
BEZEL
(OPTION)
Required(couple)
Not required
POWER OUTPUT FOR
TRANSDUCER
+24VDC, 4mA (input code:1)
-24VDC,20mA (input code:2)
1CH : -24VDC, 40mA 2CH : -24VDC, 20mA (input code:3)
1CH : -24VDC, 20mA 2CH : +24VDC, 4mA (input code:4)
EXTERNAL CONTACT
INPUT
(FROM REAR PANEL)
Contact for alarm reset (normally open)
Contact for sequence (normally open)
Contact type : Dry contact
INSULATION
RESISTANCE
Between power supply and GND : 100MΩ or more at 500VDC
Between GND and alarm contact : 100MΩ or more at 500VDC
DIELECTRIC STRENGTH Between power supply and GND : 1500VAC, one minute
POWER
CONSUMPTION
VM-5G0 : 40VA or less
VM-5G1 : 30W or less
VM-5G2 : 40W or less
OTHERS
RELAY POINTS 5 points(DANGER1,ALERT1,DANGER2,ALERT2,OK)
TEMPERATURE
RANGE
Operating temperature : 0 to 65°C (32 to 149°F)
Storage temperature : -30 to +85°C (-22 to +185°F)
Relative humidity : 20 to 95% (noncondensing)
CONTACT RATING
(LOAD RESISTANCE)
250VAC,0.2A 30VDC,2A
CONTACT LIFE 100,000 times or more(rated load)
CONTACT METHOD SPDT(DAN.1,DAN.2,ALE.1,ALE.2,OK)5 points relay
MATERIAL AND FINISH
Rack : SPCC Unichromate plating finish (black)
Rear plate : SPCC Unichromate plating finish (black)
Bezel : Aluminum Munsell N-1.0 (equiv.)
PROTECTIVE
CONSTRUCTION
Plastic sealed MASS Rack : max.1.8kg
Bezel : max.0.2kg
Alarm contact operation
Monitor power ON
Monitor alarm relay mode Monitor power OFF
Normal state Alarm state
NO contact NORMALLY DE-ENERGIZED OPEN OPEN CLOSE
NO contact NORMALLY ENERGIZED OPEN CLOSE OPEN
NC contact NORMALLY DE-ENERGIZED CLOSE CLOSE OPEN
NC contact NORMALLY ENERGIZED CLOSE OPEN CLOSE
Note) Ventilation holes are drilled through the top, bottom and side faces of the instrument rack for natural
cooling. When mounting the instrument rack within the panel, do not close these ventilation holes. I
f
closed, the temperature in the rack may rise to shorten the service life of electronic parts used.
Do not place anything which interrupts ventilation within 200 mm from top and bottom faces of th
e
instrument rack.
Do not place the apparatus which generates heat under the instrument rack.
Be careful when installing the instrument rack in a bad-ventilated closed box (instrument panel).
It may cause shortening the life time of electronic parts because of marked rising in temperature of th
e
instrument rack in a bad-ventilated closed box which keeps the heat in.
Cool down inside the box with a cooling fan or the like.
Especially when installing in a small closed box, use the forced-air cooling apparatus like an electronic ai
r
conditioner.
/TRP/CEM
Ordering Information Standard Specifications
VM-5G
-
Note) This code is applicable only to Model VM-5G.
Model Code / Additional Spec. Code( )
No entry if additional
spec. code is not specified.
Note) *1 2-wire transducer requiring a constant current power supply
(+24VDC, 4mA).
*2 3-wire transducer requiring a -24VDC power supply,
or any other transducer that does not cause power to be
supplied from the monitor to the transducer.
*3 Power supply is 0,2 : Can not select.
Standard Specifications
39516E4.3
