7. UNIT
INSTALLATION
VM-5G
-15-
7-3
REMOVAL OF POWER SUPPLY UNIT
•
Make sure to turn off the power.
•
Failure to turn off the power before pulling
the monitor unit out of the instrument rack
will result in serious damage and accidents.
1)
Remove the screws at the
top and bottom
of the power sup
ply unit.
2)
Pull out power supply unit.
•
Make sure not to touch the chassis.
Mandatory
Caution
Prohibition
20
22
