ShoreTel IP Phone 930D Quick Reference
Monitored Extension
Signal strength indicator
Handset is active
Speakerphone is active
Wired headset is active
Transmitted audio is muted
Battery strength indicator
Idle, on hook
Off hook, dialing
Idle, Do Not Disturb (DND)
Incoming call (animated)
Connected call
Conference call
Call on hold locally (animated)
Call on hold remotely
Call is being recorded (animated)
Active whisper call
Monitored extension idle
Monitored extension idle, DND
Unheard voice messages
Unheard voice messages, DND
On a call
Call on hold locally
Connected call and incoming call
On a conference call
Monitored extension on a connected
call, another call answered locally
Monitored extension on hold, anoth-
er call answered locally (animated)
Monitored extension on a connected
call, another call on hold (animated)
Monitored extension on hold, another
call on hold (animated)
Speed dial extension
Speed dial extension with DND
Speed Dial
Security
Secure call
Secure conference call
GUIDE TO STATUS ICONS
PN 800-1826-01
Status Bar
The ShoreTel logo and ShorePhone are trademarks of ShoreTel, Inc. in the United States and/or other countries. The ShoreTel IP Phone 930D is covered by patents as listed at http://www.shoretel.com/about/patents.html. The product is also
covered by other pending patent applications. ShoreTel, Inc. All rights reserved.
Call Appearance
End/Power button
Speakerphone button
Indicator LED:
- Double red ash: Incoming call
- Red ash: Message waiting
- Green ash: Low battery
- Amber ash: Out of range
Transfer button
#/Voicemail
button
LCD display area
Soft Keys
(context-sensitive
functions dened on
LCD display area)
Dial pad
Talk button
Menu button
Four-way controller
with center select button
Conference
button
Redial button
Hold button
Headset jack
Volume up/down
buttons
Mute button
Belt clip holes
Unheard voice messages
Missed calls
Logged in to workgroup
Logged in to workgroup, in wrap-up
Logged out of workgroup
Main Display
Battery cover
