SHOWTEC Pixel bar 12 User Manual

14
3. DMX Mode
With this menu you can set the DMX address.
1) Press the MODE button, until the display shows .
2) You can choose 512 different DMX addresses.
Use the Up / Down buttons to select the required address from .
Press Setup to enter the Channel Menu. You can choose 8 different channel menus.
3 channels
4 channels
6 channels
7 channels
9 channels
12 channels
18 channels
36 channels
4. Master/Slave Mode
When the display shows : , the device is a slave device. It will now react the same as its master.
5. Sound control Mode
1) Press the MODE button on the device, until the display shows SOUd. Turn on the music and the LED
Pixel Bar will react to the beat of the music.
