SHOWTEC Pixel bar 12 - DMX Channel Configurations: 7-Channel; 7-Channel Mode

17
7 DMX Channels
Channel 1 – Red
0-255
Gradual adjustment Red from 0 – 100%
Channel 2 – Green
0-255
Gradual adjustment Green from 0 – 100%
Channel 3 – Blue
0-255
Gradual adjustment Blue from 0 – 100%
Channel 4 – Master Dimmer
0-255
Gradual adjustment from black to brightest
Channel 5 – Built-in Programs
0-6
No Function
7-13
Program 1
14-20
Program 2
21-27
Program 3
28-34
Program 4
35-41
Program 5
42-48
Program 6
49-55
Program 7
56-62
Program 8
63-69
Program 9
70-76
Program 10
77-83
Program 11
84-90
Program 12
91-97
Program 13
98-104
Program 14
105-111
Program 15
112-118
Program 16
119-125
Program 17
126-132
Program 18
133-139
Program 19
140-146
Program 20
147-153
Program 21
154-160
Program 22
161-167
Program 23
168-174
Program 24
175-181
Program 25
182-188
Program 26
189-195
Program 27
196-202
Program 28
203-209
Program 29
210-216
Program 30
217-223
Program 31
224-230
Program 32
231-237
Program 33
238-244
Program 34
245-251
Program 35
252-255
Sound Active
Channel 6 – Speed (when CH5 is set between 7-251 )
0-255
Speed from slow to fast
Channel 6 – Audio Sensitivity (when CH5 is set between 252-255 )
0-255
Audio sensitivity from less sensitive to highly sensitive
Channel 7 – Master Dimmer
0-169
Sound Mode S1
170-255
Black Out
