SHOWTEC Pixel bar 12 - DMX Channel Configurations; 3-Channel Mode; 4-Channel Mode; 6-Channel Mode

16
3 DMX Channels
Channel 1 – Red
0-255
Gradual adjustment Red from 0 – 100%
Channel 2 – Green
0-255
Gradual adjustment Green from 0 – 100%
Channel 3 – Blue
0-255
Gradual adjustment Blue from 0 – 100%
4 DMX Channels
Channel 1 – Red
0-255
Gradual adjustment Red from 0 – 100%
Channel 2 – Green
0-255
Gradual adjustment Green from 0 – 100%
Channel 3 – Blue
0-255
Gradual adjustment Blue from 0 – 100%
Channel 4 – Dimmer
0-255
Gradual adjustment from black to brightest
6 DMX Channels
Channel 1 – Red Section 1
0-255
Gradual adjustment Red from 0 – 100%
Channel 2 – Green Section 1
0-255
Gradual adjustment Green from 0 – 100%
Channel 3 – Blue Section 1
0-255
Gradual adjustment Blue from 0 – 100%
Channel 4 – Red Section 2
0-255
Gradual adjustment Red from 0 – 100%
Channel 5 – Green Section 2
0-255
Gradual adjustment Green from 0 – 100%
Channel 6 – Blue Section 2
0-255
Gradual adjustment Blue from 0 – 100%
